Signal Analyzer -TDM800

A Signal Analyzer is an electronic measuring instrument used to measure the properties and parameters of electrical signals. It usually consists of a variety of input interfaces and displays, which can be connected to various signal sources and sensors to measure and analyze the characteristics of the signal.


Signal analyzers can be used for a variety of applications such as signal measurement, noise analysis, spectrum analysis, electromagnetic compatibility testing, etc. It can help engineers and scientists better understand and control the properties of various signals to meet specific needs and applications.


Product Features

OSENS is driven by technological innovation and constantly pursues better quality

Widely Applicable

Comprehensive functional portfolio

Small Size

Lighter weight and more practical

Strong Anti-jamming

Rigorously designed and tested


Reliable Performance

Ensure safety and reliability








Technical Parameters

Input channel:8-channel

Output channel:

USB

Support driver:

WDM, Core Audio,ASIO

Sample rate:

48kHz

Logic voltage:

3.3V

TDM_CLK:

12.288MHz

Frequency response:

±0.005dB (20~20kHz)

THD:

0.0002%

Output background noise:

-143dB

Signal to noise ratio:

107dB(-34dBFs/1kHz)

Size:

150*130*35mm

Weight:

900g


"We have successfully reduced the cost and time of production testing, helping enterprises to achieve efficient production."
